Head: 0-50m
Flow: 0-225m³/h
Material: PVDF, cast iron
Voltage: 380V
MHF-D50-32-125
1 2 3 4
1-Model No.：MHF一 Monoblock fluorine-lined pump
2-Inlet：50:2"
3-Outlet：32:1-1/4"
4-Impeller diameter：125mm
Chemical cast iron centrifugal pump with PVDF lining: the power of metal and the durability of fluoroplastic
A centrifugal pump with a cast iron body and PVDF (polyvinylidene fluoride) lining is powerful and reliable equipment designed for pumping aggressive chemical media under high loads. It combines the strength of metal and the chemical resistance of fluoroplastic, ensuring a long service life even in the most difficult conditions.
⚙️ Specifications
Pump type: centrifugal, horizontal
Body: high-strength cast iron, with anti-corrosion protection
Lining: PVDF (polyvinylidene fluoride)-one of the most durable fluoroplastics
Maximum pressure: up to 50 m
Maximum capacity: up to 225 m³/h
Working medium temperature: up to +95°C
Power supply: 380 V, three-phase
Seal type: mechanical or magnetic clutch (optional)
Advantages of PVDF lining
PVDF (polyvinylidene fluoride) is a heat-resistant fluoroplastic, resistant to:
aggressive acids (including hydrofluoric, sulfuric, nitric),
alkalis, oxidizers, solvents, salts,
UV radiation and temperature changes.
At the same time, it remains stable at high pressures and under constant chemical attack.
✅ Pump advantages
Durable cast iron body — reliability and resistance to mechanical stress
PVDF lining — maximum chemical protection of internal elements
️ Handling hot and aggressive liquids
Low vibration and noise
⚙️ High pressure and capacity — up to 50 m and 225 m³/h
Industrial power supply 380 V — suitable for most industries
Application
Chemical production
Petrochemical and paint and varnish industry
Fertilizer and acid production
Wastewater treatment and pumping of aggressive reagents
Galvanic processes, electronics
Metallurgy, battery production
When is it worth choosing a cast iron pump with lining?
This pump is the ideal solution if:
High mechanical strength is required (for example, with a pressure above 40 m)
You work with aggressive chemicals
Durability is important under intensive use
Standard plastic pumps cannot handle the load
Selection of equipment and consultation
We will select the optimal model for your process: by medium composition, temperature, pressure and operating mode.
